Product Details:
Place of Origin: Sichuan, China
Brand Name: Joiner
Certification: ISO9001-2015
Model Number: CWJ 63
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard packing (wooden box)
Delivery Time: 60 - 90 days
Payment Terms: L/C,T/T
Supply Ability: 100 sets per year
Contact Now
Detailed Product Description
Barrel Diameter: Ø 63.5 Mm Screw Diameter: Ø 62.8 Mm
Condition: New Warranty: 6 Months
Groove Depth: 16.9 Mm Length Of Screw: 504 Mm
L/D: 8:1 Color: As Request
Motor Power: 5.5 Kw Reducer Ratio: 10:1
Screw Design: Double-screw After-sales Service Provided: Online Support
High Light:

Corrosion Resistant Co Rotation Side Feeder

,

Nitriding Co Rotation Side Feeder

,

SS Twin Screw Extruder Side Feeder



High Performance Auxiliary Machine Side Feeder For Double Screw Extruder


All Joiner Screw elements are manufactured using only top quality wear and corrosion resistant steels. Tooling steel, Nitriding, stainless steels and alloys or specially imported treated materials are all available depending on the customers specific requirements.

1. Our side feeders features :
a· Very durable thanks to its durable integral liner inside barrels
b· The tightly intermeshing co-rotating segments with various pitch have an improved conveying behavior and ensure the precision (long GF±5%,short GF±2%) and output (caco3 550Kg/h, GF 500Kg/h)
c· More human centered design, ease of operation, for example the glass window, on the splined sleeve, flat screw head, the adjustable support and the drawer for clean up the leak can be designed based on user requests.

Mark Part Name Qty (Pcs) Function
1 SEW Motor 1 Driving System
2 Gearbox Section 1 Transmission System
3 Hopper 1 Feeding
4 Screw Section 2 Mixing and conveying the filler
5 Barrel Section 2 Carry the screw shaft and melt the material
6 Bracket 2 Supporting the Side Feeder


2. Advantages of Joiner Extrusion Side Feeder

1). Independently develop and produce gearboxes.
a. All gearboxes are machined by gear grinding, the accuracy is up to six grades, and carburizing and hardening the tooth surface, thus ensuring that the noise of gearboxes is very low.
b. Gear casting is made of resin sand and machining center to ensure high precision.
c. the gearbox’s bearing is imported from Germany.
d. the gearbox has unique design, long life and low noise.
e. the gearbox and screw element are connected by spline sleeve, which is very convenient to disassemble

2). Barrel is made of wear resistant alloy steel and cooled by water channel.

3). Screw adopts modular screw, and the screw assembly can be adjusted according to different feeding materials to meet different feeding requirements.

3. Side feeders are used for the following reasons:

--reduction of wear costs in the melting section of the main screw and barrels
--More gentle processing of fillers
--Increase in throughput
--Increase in quality through the enough fixing
--Lower the cost




4. Models: CWJ side feeder range is available with a screw diameter from 25mm to 130mm.



High Performance World First-Class Brand Double Screw Extruder Auxiliary Machine Side Feeder For 0


5. Production and Inspection of Equipment
Our factory is state-of-the art and spans over 20,000 square meters. The factory houses more than 140 sets of different domestic and foreign high precision production equipment, with the degree of numerical control up to 95%.

High Performance World First-Class Brand Double Screw Extruder Auxiliary Machine Side Feeder For 1




6. Packing and Delivery
Packing Details : Standard export packing
1).Standard packing with wooden box.
2)Suitable carton size;
3)Shock bubble film

Delivery Time: Shipped in 60 days after payment for Side Feeder.

High Performance World First-Class Brand Double Screw Extruder Auxiliary Machine Side Feeder For 2
